Stainless steel slides

Full extension ball-bearing slide (3 pieces), front disconnect and positive lock

LG = slide length.
K = travel length.
CN = load rating (kg/pair).

Sold by the unit.

Quotation request

Part number

Material

Finish

A

B

C

D

E

F

G

H

Weight (g)

CN (load rating)

K

LG (slide length)

Sheet	cao

21-7-3569

304 stainless steel

raw

250.8 mm

361.9 mm

374.6 mm

0

0

349.2 mm

361.9 mm

374.6 mm

840 g

57

421.7

406.4

21-7-3570

304 stainless steel

raw

301.6 mm

412.7 mm

425.4 mm

212.7

0

400 mm

412.7 mm

425.4 mm

950 g

53

472.5

457.2

21-7-3571

304 stainless steel

raw

352.4 mm

463.5 mm

476.2 mm

238.1

0

450.8 mm

463.5 mm

476.2 mm

1030 g

49

523.3

508

21-7-3572

304 stainless steel

raw

403.2 mm

514.3 mm

527 mm

263.5

415.9 mm

501.6 mm

514.3 mm

527 mm

1150 g

45

574.1

558.8

21-7-3573

304 stainless steel

raw

454 mm

565.1 mm

577.8 mm

288.9

466.7 mm

552.4 mm

565.1 mm

577.8 mm

1280 g

42

624.9

609.6

21-7-3574

304 stainless steel

raw

504.8 mm

615.9 mm

628.6 mm

314.3

517.5 mm

603.2 mm

615.9 mm

628.6 mm

1400 g

39

675.7

660.4

21-7-3575

304 stainless steel

raw

555.6 mm

666.7 mm

679.4 mm

339.7

568.3 mm

654 mm

666.7 mm

679.4 mm

1500 g

36

726.5

711.2

Scroll horizontally
