Friction hinges
The friction torque is adjustable with a hex key.
2 other versions available: with spring or with detent function.
Small symmetrical friction pin hinges
Small size friction hinge to maintain a lid / door in position.The friction torque is adjustable with a hex key.
2 other versions available: with spring or with detent function.
| Axial load | Radial load | Load with 90° angle | |
|---|---|---|---|
| Tensile tests |  |
 |
 |
| References | Maximum load (N) | Maximum load (N) | Maximum load (N) |
| 59-7-5016 | 1480 | 2460 | 2400 |
| 59-7-5017 | 1480 | 2460 | 2400 |
The values stated are derived from the tests carried out by PINET according to the conditions mentioned in the link below.This does not replace in any way the calculations or validation tests that the customer must make on his application with the hinge.
Test conditions and protocols
Small symmetrical friction pin hinges
Part number : 59-7-5015
| Available stock | Unit price |
| 2 | 66.82 € excl. taxes |
To order, register or login click on
Log inSmall symmetrical friction pin hinges
Part number : 59-7-5016
| Available stock | Unit price |
| 0 | 66.82 € excl. taxes |
To order, register or login click on
Log inSmall symmetrical friction pin hinges
Part number : 59-7-5017
| Available stock | Unit price |
| 45 | 75.17 € excl. taxes |
To order, register or login click on
Log in
