Spring hinges - aluminium profile
M(0°): 3.80 N.m / M(90°): 3.10 N.m / M(180°): 2.40 N.m
Closing spring force:
M(0°): 2.20 N.m / M(90°): 2.90 N.m / M(180°): 3.50 N.m
Free swinging hinge without spring available (part number: 72-1-4241 in colorless or 72-1-4242 in black).
Spring hinges - aluminium profile 3.80 N.m - diameter 18
Opening spring force:M(0°): 3.80 N.m / M(90°): 3.10 N.m / M(180°): 2.40 N.m
Closing spring force:
M(0°): 2.20 N.m / M(90°): 2.90 N.m / M(180°): 3.50 N.m
Free swinging hinge without spring available (part number: 72-1-4241 in colorless or 72-1-4242 in black).
| Axial load | Radial load | Load with 90° angle | |
|---|---|---|---|
| Tensile tests |  |
 |
 |
| References | Maximum load (N) | Maximum load (N) | Maximum load (N) |
| 72-1-4231 | 11900 | 9000 | 8730 |
| 72-1-4232 | 11900 | 9000 | 8730 |
| 72-1-4258 | 11900 | 9000 | 8730 |
| 72-1-4259 | 11900 | 9000 | 8730 |
| 72-1-4331 | 11900 | 9000 | 8730 |
| 72-1-4332 | 11900 | 9000 | 8730 |
The values stated are derived from the tests carried out by PINET according to the conditions mentioned in the link below.This does not replace in any way the calculations or validation tests that the customer must make on his application with the hinge.
Test conditions and protocols
