Heavy duty aluminium profile hinges

Rectangular hinges

Heavy duty aluminium profile hinges

Free swinging hinge.
It has the same footprint and design as the spring hinge for heavy duty applications (part numbers: 72-1-4231, 72-1-4232, 72-1-4258 and 72-1-4259).
All are fully interchangeable.

Quotation request

Part number

	Load	Stock

Material

Finish

Weight (g)

Sheet	cao	Load	Stock

72-1-4241

6082 T5 alu

clear anodised

100 mm

82.5 mm

5.5 mm

149 g

72-1-4242

6082 T5 alu

black anodised

100 mm

82.5 mm

5.5 mm

150 g

Scroll horizontally

Aluminiumprofil-Scharniere für Verstärkte Ausführung

	Axial load	Radial load	Load with 90° angle
Tensile tests
References	Maximum load (N)	Maximum load (N)	Maximum load (N)
72-1-4241	14080	9190	8430
72-1-4242	14080	9190	8430

The values stated are derived from the tests carried out by PINET according to the conditions mentioned in the link below.This does not replace in any way the calculations or validation tests that the customer must make on his application with the hinge.

Test conditions and protocols
